| OVERVIEW |
| Accuracy |
±4°C (±7.2°F) or ±4% of reading, for ambient temperature 10°C to 35°C (50°F to 95°F) |
| Detector Type |
Focal plane array (FPA), uncooled microbolometer |
| Focal Length |
9 mm (0.35 in.) |
| IR Resolution |
240 × 180 pixels |
| Langues |
English |
| Object Temperature Range |
–20°C to 150°C (–4°F to 302°F) 0°C to 650°C (32°F to 1202°F) |
| Packaging Size |
500 × 190 × 370 mm (19.7 × 7.5 × 14.6 in.) |
| Set-up Commands |
Local adaptation of units, date and time formats |
| Thermal Sensitivity/NETD |
<40 mK @ 30°C (86°F) |
| Compatible with FLIR software |
FLIR Tools® |
| CONNECTIONS & COMMUNICATIONS |
| Interface |
Update from PC devices Data transfer to and from PC |
| USB |
USB Mini-B |
| ENVIRONMENTAL |
| Directives |
Designed to meet NFPA 1801:2013 specification: Vibration Impact acceleration resistance Corrosion Viewing surface abrasion Heat resistance Heat and flame Product label durability |
| Drop |
2 m (6.6 ft.) on concrete floor (IEC 60068-2-31) |
| EMC |
EN 61000-6-2:2005 (Immunity) EN 61000-6-3: 2011 (Emission) FCC 47 CFR Part 15 B (Emission) |
| Encapsulation |
IP 67 (IEC 60529) |
| Humidity (Operating and Storage) |
IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C (+77°F to +104°F) / 2 cycles |
| Magnetic fields |
EN 61 000-4-8, Test level 5 for continuous field (severe industrial environment) |
| Operating Temperature Range |
–20°C to 85°C (–4°F to 185°F) 150°C (302°F): 15 min. 260°C (500°F): 5 min. |
| Relative Humidity |
95% relative humidity +25°C to 40°C (77°F to 104°F) non-condensing |
| Shock |
25 g (IEC 60068-2-27) |
| Storage Temperature Range |
–40°C to 85°C (–40°F to 185°F) |
| Tripod Mounting |
UNC ¼"-20 (adapter needed) |
| Vibration |
2 g (IEC 60068-2-6) |
| IMAGING & OPTICAL |
| Camera size (L x W x H) |
120 × 125 × 280 mm (4.7 × 4.9 × 11 in.) |
| Camera weight incl battery |
1.1 ±0.05 kg (2.4 ±0.1 lb.) |
| Contrast optimization |
Digital image enhancement using FSX |
| Depth of Field |
0.84 m to infinity (33 in. to infinity) |
| f-number |
1.25 |
| Field of view (FOV) |
51° × 38° |
| Focus |
Fixed |
| Image Frequency |
60 Hz |
| Image Modes |
TI Basic fire-fighting mode |
| Non-radiometric IR video streaming |
Uncompressed colorized video using USB |
| Pitch |
25 µm |
| Spatial resolution (IFOV) |
3.6 mrad |
| Spectral Range |
7.5–13 µm |
| MEASUREMENT & ANALYSIS |
| Isotherm |
Yes |
| Spot Meter |
1.0 |
| Meter Data |
| Auto Range |
Yes, selectable on/off using FLIR Tools® |
| Display |
4 in. LCD, 320 × 240 pixels, backlit |
| POWER |
| Battery capacity |
4.4 Ah, at 20°C to 25°C (68°F to 77°F) |
| Battery operating time |
Approx. 4 hours at 25°C (77°F) ambient temperature and typical use |
| Battery Type |
Li ion |
| Battery voltage |
3.6 V |
| Battery weight |
0.152 kg (0.3 lb.) |
| Charging system |
Battery is charged inside the camera 2-bay charger Optional In-truck charger |
| Charging Temperature |
0°C to 45°C (32°F to 113°F) |
| Charging Time |
2 h to 85% capacity, charging status indicated by LEDs |
| Power Management |
Automatic shutdown and sleep mode |
| Safety [power supply] |
CE/EN/UL/CSA/PSE 60950-1 |
| Start Up Time |
<17 s. (IR image, no GUI) |
| Start-up time from sleep mode |
<4 s. |
| SHIPPING INFORMATION |
| Material |
PPSU Silicon rubber Aluminium, cast Flame-resistant magnesium alloy |
| STORAGE MEDIA |
| Image Storage |
No JPEG storage; Image freeze: configurable |
| Image Storage Capacity |
NA |
