| Overview |
| Detector Type |
Focal plane array (FPA), uncooled microbolometer (VOx) |
| Focal Length |
9 mm (0.35 in.) |
| IR Resolution |
320 × 240 pixels |
| Languages |
English |
| Material |
PPSU Silicon rubber Aluminium, cast Flame-resistant magnesium alloy |
| Packaging Size |
500 x 190 x 370 mm (19.7 x 7.5 x 14.6 in.) |
| Pitch |
25 µm |
| Report Generation |
Separate software (FLIR Tools) |
| Set-up Commands |
Local adaptation of units, date and time formats |
| Spectral Range |
8–14 µm |
| Tripod Mounting |
UNC 1/4"-20 (adapter needed) |
| Zoom |
2× digital zoom |
| Compatible with FLIR software |
FLIR Tools |
| COMPLIANCE & CERTIFICATIONS |
| Compliance |
NFPA1801:2018
Ex-certified according to ANSI/ISA 12.12.01-2015 and meets Class I Division 2 Groups C and D
Class II Division 2 Groups F and G, Temperature Code T4/T135°Cs |
| CONNECTIONS & COMMUNICATIONS |
| Interface |
Update from PC devices Data transfer to and from PC |
| Storage Media |
Internal flash memory |
| USB |
USB Mini-B |
| ENVIRONMENTAL |
| Directives |
Certified according to NFPA 1801:2018 specification: Vibration Impact acceleration resistance Corrosion Viewing surface abrasion Heat resistance Heat and flame Product label durability |
| Drop |
2 m(6.6 ft.) on concrete floor (IEC 60068-2-31) |
| EMC |
EN 61000-6-2:2005 (Immunity) EN 61000-6-3: 2011 (Emission) FCC 47 CFR Part 15 B (Emission) |
| Encapsulation |
IP 67 (IEC 60529) |
| Humidity (Operating and Storage) |
IEC 60068-2-30/24 h 95% relative humidity +25°C to +40°C(+77°F to +104°F)/ 2 cycles |
| Magnetic fields |
EN 61 000-4-8, Test level 5 for continuous field (severe industrial environment) |
| Operating Temperature Range |
–20°C to +85°C (–4°F to +185°F) +150°C (+302°F): 15 min. +260°C (+500°F): 5 min. |
| Relative Humidity |
95% relative humidity +25°C to +40°C(+77°F to +104°F)non-condensing
|
| Shock |
25 g (IEC 60068-2-27) |
| Storage Temperature Range |
–40°C to +85°C(–40°F to +185°F)
|
| Vibration |
2 g (IEC 60068-2-6) |
| IMAGING & OPTICAL |
| Auto Range |
Yes, selectable on/off using FLIR Tools
|
| Camera size (L x W x H) |
120 x 125 x 280 mm (4.7 x 4.9 x 11 in.)
|
| Camera weight incl battery |
1.1 ±0.05 kg (2.4 ±0.1 lb.)
|
| Contrast optimization |
Digital image enhancement using FSX |
| Depth of Field |
0.84 m to infinity (33 in. to infinity) |
| Display |
4 in. LCD, 320 × 240 pixels, backlit |
| f-number |
1.25 |
| Field of view (FOV) |
51° × 38° |
| Focus |
Fixed |
| Image Frequency |
60 Hz |
| Image Modes |
IR image TI Basic fire-fighting mode Black-and-white fire-fighting mode Fire mode Search-and-rescue mode Heat detection mode Thumbnail gallery |
| Non-radiometric IR video recording |
MPEG-4 to internal flash memory |
| Non-radiometric IR video streaming |
Uncompressed colorized video using USB |
| Spatial resolution (IFOV) |
2.8 mrad |
| Storage Capacity |
200 files in total, with a maximum duration of 5 minutes each. The total number of files is co-dependent on the number of saved images. |
| MEASUREMENT & ANALYSIS |
| Accuracy |
±4°C (±7.2°F) or ±4% of reading, for ambient temperature 10°C to 35°C (+50°F to 95°F) |
| Automatic Hot Detection |
Heat detection mode (the hottest 20% of the of scene is colorized) |
| Isotherm |
Yes, according to NFPA |
| Object Temperature Range |
–20°C to +150°C (–4°F to +302°F) 0°C to +650°C (+32°F to +1202°F) |
| Spot Meter |
1.0 |
| Thermal Sensitivity/NETD |
< 30 mK @ +30°C (+86°F) |
| POWER |
| Battery capacity |
4.4 Ah, at +20°C to +25°C (+68°F to +77°F) |
| Battery operating time |
Approx. 4 hours at +25°C (+77°F) ambient temperature and typical use. This operating time is independent of camera mode. |
| Battery type |
Li Ion |
| Battery voltage |
3.6 V |
| Battery weight |
0.152 kg(0.3 lb.) |
| Charging system |
Battery is charged inside the camera 2-bay charger Optional In-truck charger
|
| Charging Temperature |
0°C to +45°C (+32°F to +113°F)
|
| Charging Time |
2 h to 85% capacity, charging status indicated by LEDs |
| Power Management |
Automatic shutdown and sleep mode |
| Safety [power supply] |
CE/EN/UL/CSA/PSE 60950-1
|
| Start Up Time |
< 17 s. (IR image, no GUI) |
| Start-up time from sleep mode |
< 4 s. |
| STORAGE MEDIA |
| File Formats |
Standard JPEG |
| Image Storage |
Standard JPEG |
| Image Storage Capacity |
200 files in total. The number of files is co-dependent on the number of saved video clips. |
| Image Storage Mode |
IR only |
