Stainless Steel PowerPak for MeshGuard
The PowerPak is an external battery used to extend the runtime of Meshguard monitors. This intrinsically safe (Class I, Division 1 and ATEX Zone 0) rechargeable battery power source is ideal for monitoring applications that require longer runtime than a standard internal battery affords.
Key Features:
- Up to 4 months continuous operation before recharging, when it contains four encapsulated internal batteries and is used with a MeshGuard (4 months), MeshGuard LEL (25 days), or MeshGuard Router (1.5 months)
- Rugged stainless-steel enclosure
- Very low-cost installation - no hardwiring involved
- Very little maintenance or monitoring
- Large, easy-to-read continuous display of power percentage and charging/error messages
- Bright 3-color status LED
- Simple operation without switches or controls
- IP-65 rated for outdoor use in harsh environments
- Unit can be replaced in hazardous location
Note: PowerPAK rechargeable products manufactured after January 1, 2017 no longer comply with CEC,400,2012,FS,002. Configurations with the RAEPowerPAK cannot be sold or shipped to OR and California.
Stainless Steel PowerPak for MeshGuard
| Display |
Customized LCD and red/orange/green LED |
| Dimensions |
14.25? H x 10.25? W x 5.75? D |
| Weight |
33 lbs with four internal batteries |
| Package |
IP-65 |
| Output
Voltage |
3.3V?0.1V |
| Maximum
Output
Current |
0.33A |
| Capacity |
Two internal battery units: 26Ah
Four internal battery units: 52Ah |
| Mounting |
Stainless-steel wall-mount plate |
| Options |
Stainless-steel or zinced steel version |
Stainless Steel PowerPak for MeshGuard
